Product Specification
|
8S6P |
12S4P |
16S3P |
24S2P |
|
|
Nominal Voltage (V) |
18.4 |
27.6 |
36.8 |
55.2 |
|
Nominal Capacity (Ah) |
144 |
96 |
72 |
48 |
|
Nominal Energy (kWh) |
＞2.6 |
|||
|
Operating Voltage Range (V) |
12~23.2 |
18~34.8 |
24~46.4 |
36~69.6 |
|
Continuous Charging Current (A) |
280 |
|||
|
Continuous Discharging Current (A) |
280 |
|||
|
Maximum Pulse Charging Current (A) |
350 |
|||
|
Maximum Pulse Discharging Current (A) |
350 |
|||
|
Dimensions (mm) |
546.5±1.0×234±0.5×132±0.5 |
|||
|
Weight (kg) |
≈33 (Actual design may vary) |
|||
|
Energy Density (Wh/kg) |
82.8 |
|||
|
Operating Temperature (°C) |
-40~80 |
|||
|
Storage Temperature (°C) |
-20~50 |
|||
|
Packaging Method |
Aluminum side welding/plastic steel strip |
|||
